額定載荷Rated Load
|
15T、20T
|
|
額定輸出Rated Output
|
2.0000±0.001MV/V
|
|
綜合誤差Total Error
|
±0.1%F.S
|
|
蠕變Creep(30minutes)
|
±0.02%F.S
|
|
推薦工作電壓Recommended Excitation Voltage
|
5V～12V(AC or DC)
|
|
最大工作電壓Maximum Excitation Voltage
|
15V(AC or DC)
|
|
零點平衡Zero Balance
|
±1%F.S
|
|
輸入阻抗Input Impedance
|
380±5Ω
|
|
輸出阻抗Output Impedance
|
350±2Ω
|
|
絕緣阻抗Insulation Impedance
|
≥5000MΩ
|
|
安全過載率Safe Overload
|
150%F.S
|
|
極限過載率Ultimate Overload
|
200%F.S
|
|
工作溫度范圍Operating Temperature Range
|
(-30～+70)℃
|
|
溫度補償范圍Compensated Temperature Range
|
(-20～+60)℃
|
|
輸出溫度影響Temperature Effect On Load
|
±0.02%F.S/10℃
|
|
零點溫度影響Temperature Effect On Zero
|
±0.02%F.S/10℃
|
|
材質Construction
|
合金鋼Alloy Steel
|
|
防護等級Protection Class
|
IP68&IP67
|
|
引用標準Citation
|
GB/T7551-2008/OIML R60
|
|
接線方式Mode of Connection
|
輸入+:紅 Input+:Red
輸入-:綠 Input-: Green
輸出+:黃Output+:Yellow
輸出-:白 Output-:White
|
